Delta KPMS-LE01 User Manual

Chapter 3 InstallationMS300
20
Frame
Airflow Rate for Cooling
Power Dissipation for AC Motor Drive
Model No.
Flow Rate
(Unit: cfm)
Flow Rate
(Unit: m
3
/ hr)
Loss External
(Heat sink, unit: W)
Internal
(Unit: W)
Total
(Unit: W)
C
VFD5A5MS43ANSAA
VFD5A5MS43ENSAA
VFD5A5MS43AFSAA
16.0
27.2
60.6
22.8
83.4
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
75.2
30
105.2
VFD9A0MS43ANSAA
VFD9A0MS43ENSAA
VFD9A0MS43AFSAA
93.1
42
135.1
VFD4A2MS53ANSAA
46.6
22.2
68.8
VFD6A6MS53ANSAA
76.1
30
106.1
D
VFD25AMS23ANSAA
VFD25AMS23ENSAA
23.4
39.7
192.8
53.3
246.1
VFD13AMS43ANSAA
VFD13AMS43ENSAA
VFD13AMS43AFSAA
132.8
39.5
172.3
VFD17AMS43ANSAA
VFD17AMS43ENSAA
VFD17AMS43AFSAA
164.7
55.8
220.5
VFD9A9MS53ANSAA
93.9
37
130.9
VFD12AMS53ANSAA
108.4
51
159.4
E
VFD33AMS23ANSAA
VFD33AMS23ENSAA
53.7
91.2
244.5
79.6
324.1
VFD49AMS23ANSAA
VFD49AMS23ENSAA
374.2
86.2
460.4
VFD25AMS43ANSAA
VFD25AMS43ENSAA
VFD25AMS43AFSAA
234.5
69.8
304.3
VFD32AMS43ANSAA
VFD32AMS43ENSAA
VFD32AMS43AFSAA
319.8
74.3
394.1
F
VFD65AMS23ANSAA
VFD65AMS23ENSAA
67.9
115.2
492.0
198.2
690.2
VFD38AMS43ANSAA
VFD38AMS43ENSAA
VFD38AMS43AFSAA
423.5
181.6
605.1
VFD45AMS43ANSAA
VFD45AMS43ENSAA
VFD45AMS43AFSAA
501.1
200.3
701.4
Table 3-2

Delta KPMS-LE01 Specifications

General

Brand	Delta
Model	KPMS-LE01
Category	DC Drives
Language	English
