Delta (Model TS220LS) User Manual

9
Fig. 4
STAND PARTS
49 - Leg (4)
50 - 3/8” Flat Washer for Mounting Saw to Stand & for Assembling Stand (24)
51 - Foot (4)
52 - M8x1.25 Hex Nut for Mounting Saw to Stand & for Assembling Stand (20)
53 - M8x1.25x40mm Hex Screw for Mounting Saw to Stand (4)
54 - M8x1.25x20mm Carriage Bolts for Assembling Stand (16)
55 - 18-1/2” Top Front and Rear Brackets (2)
56 - 17” Top Side Brackets (2)
57 - 22” Bottom Front and Rear Brackets (2)
58 - 20-3/8” Bottom Side Brackets (2)
49
56
57
55
58
51
54
50
52
53
FOR YOUR OWN SAFETY, DO NOT CONNECT THE MACHINE TO THE POWER SOURCE UNTIL
THE MACHINE IS COMPLETELY ASSEMBLED. DO NOT OPERATE THIS MACHINE UNTIL YOU READ AND
UNDERSTAND THE ENTIRE INSTRUCTION MANUAL
