English-10
NC200P-LI-A_ (rear view)
No. Item
(1) Remote I/O
(3) Spindle
(7) CF Card
(8) DMCNET
(9) EtherCAT
(11) Battery holder
(12) 24 V
DC
Power
(15) HSI
(16) Local I/O Input
(17) Local I/O Output
(18) 24 V
DC
power for the secondary panel
