M4 Hexagon Socket Screw M4 Hexagon Socket Screw
Figure 3-5 Attach inverter to the bracket and fasten with screws
CAUTION !
• The bracket supplied with the unit is specially designed and should be
the only mounting device used for the unit.
•
It is recommended to install the inverter in a suitable location which offers
non-obscured and safe access, in turn ensuring easy access for service
and maintenance.
• Please leave an appropriate gap between floor, ceiling, and unit when
installing inverter as shown in Figure 3-6. (There is no mandatory
requirement of the gap between unit and unit.)
• Please install solar inverter at an eye level to allow easy observation for
operation and parameter setting.
• Ambient temperature -25
° C~60° C.(power de-rating above 40° C)
DRM
12
Installation
