SYSTEM INFORMATION / COMMUNICATION
User interface
Black-on-white character type LCD display
365 days data logger and real time clock
30 event record
External communication 2 RS-485 connections
REGULATIONS & DIRECTIVES
CE conformity Yes
Grid interface
VDE0126-1-1, VDE-AR-N 4105, AS4777
Emission EN 61000-6-3
Harmonics EN 61000-3-2
Variations and flicker EN 61000-3-3
EN 61000-3-12
EN 61000-3-11
Immunity EN 61000-6-2
Immunity
ESD IEC 61000-4-2
RS IEC 61000-4-3
EFT IEC 61000-4-4
Surge IEC 61000-4-5
CS IEC 61000-4-6
PFMF IEC 61000-4-8
Electrical safety IEC 62109-1/ -2
MISCELLANEOUS
Enclosure
Mounting bracket
Aluminum with powder coating
Table 9-1 Specifications for RPI M6A/ M8A/ M10A
(1) 4.99kW max. for Australia (AU / NZ PL 4.99kW).
(2) 6.3kW max. for Australia (AU / NZ).
RPI M6A RPI M8A RPI M10A
51
Technical Data
