Delta VFD-L User Manual

15
Dimensions
60.0 [2.36]
100.0 [3.94]
80.0 [3.15]
POWER
ALARM
Hi gh
Low
RUN
REVFWD
STOP
RS485
90.0 [3.54]
52.5 [2.07]
80.0 [3.15]
135.7 [5.34]
52.5 [2.07]
125.1 [4.93]8.0 [0.31]
2.7 [0.11]
4
.
5
[
0
.
1
8
]
VFD001L11A
VFD001L21A
VFD40WL11A
VFD40WL21A
W/T3
N/L2
V/T2
U/T1
L/L1
Unit: mm [inch]
145.1 [5.71]
2.7 [0.11]
8.0 [0.31]
VFD001L11B
VFD001L21B
52.5 [2.07]
VFD40WL11B
VFD40WL21B
155.7 [6.13]60.0 [2.36]
Hi gh
STOP
FWD
100.0 [3.94]
RUN
REV
ALARM
POWER
Low
90.0 [3.54]
52.5 [2.07]
RS485
4
.
5
[
0
.
1
8
]
80.0 [3.15]
80.0 [3.15]
W/T3
N/L2
V/T2
U/T1
L/L1
Unit: mm [inch]
SCREW
M4 or Tapping 4(2x)
81
+1
- 0
[3.19]
53
+
1
-
0
[
2
.
0
9
]
90± 0.2 [3.54]
Unit : mm [inch]

Delta VFD-L Specifications

General

Series	VFD-L
Control Method	V/F Control
Enclosure Rating	IP20
Type	AC Motor Drive
Output Frequency	1.0 ~ 400 Hz
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Braking Unit	Built-in
Communication	RS-485 (Modbus ASCII/RTU)
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C ~ 60°C
Humidity	90% RH or less (non-condensing)
Altitude	Up to 1000m without derating
Cooling Method	Fan Cooled
Input Voltage	Single-phase 200-240V
