Chapter 7 Optional AccessoriesC2000 Plus
7-18
Model HP
Rated
Current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Input AC
reactor
Delta part #
Weight
(kg)
Heat
Dissipation
(W)
VFD750C23A-00
VFD750C23A-21
100 255 459 0.049 0.083 Yes DR276AP049 37 200
VFD900C23A-00
VFD900C23A-21
125 346 622.8 0.037 0.061 Yes DR346AP037 40 240
200V–230V, 50/60 Hz / Super Heavy Duty
Model HP
Rated
Current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Input AC
reactor
Delta part #
Weight
(kg)
Heat
Dissipation
(W)
VFD007C23A-21
1 3 6 4.227 7.045 No N/A N/A N/A
VFD015C23A-21
2 5 10 2.536 4.227 No DR005A0254 1.2 21
VFD022C23A-21
3 8 16 1.585 2.642 No DR008A0159 1.7 37
VFD037C23A-21
5 11 22 1.152 1.922 No DR011A0115 2.5 38
VFD055C23A-21
7.5 17 34 0.746 1.243 No DR017AP746 3.2 40
VFD075C23A-21
10 25 50 0.507 0.845 No DR025AP507 3.8 61
VFD110C23A-21
15 33 66 0.32 0.534 No DR033AP320 4.5 60
VFD150C23A-21
20 49 98 0.216 0.359 No DR049AP215 6.5 70
VFD185C23A-21
25 65 130 0.163 0.271 No DR065AP162 8.5 83
VFD220C23A-21
30 75 150 0.169 0.282 No DR075AP170 10 150
VFD300C23A-00
VFD300C23A-21
40 90 180 0.141 0.235 Yes DR090AP141 11.5 120
VFD370C23A-00
VFD370C23A-21
50 120 240 0.106 0.176 Yes DR146AP087 22 110
VFD450C23A-00
VFD450C23A-21
60 146 292 0.087 0.145 Yes DR146AP087 22 110
VFD550C23A-00
VFD550C23A-21
75 180 360 0.07 0.117 Yes DR180AP070 26 120
VFD750C23A-00
VFD750C23A-21
100 215 430 0.059 0.098 Yes DR215AP059 30 150
VFD900C23A-00
VFD900C23A-21
125 255 510 0.049 0.083 Yes DR276AP049 37 200
380V–460V, 50/60 Hz / Heavy Duty
Model HP
Rated
Current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Input AC
reactor
Delta part #
Weight
(kg)
Heat
Dissipation
(W)
VFD007C43A-21 1 3 5.4 8.102 13.502 No DR003A0810 1.5 20
VFD015C43A-21 2 4 7.2 6.077 10.127 No DR004A0607 1.8 21
VFD022C43A-21 3 6 10.8 4.050 6.752 No DR006A0405 2.8 31
VFD037C43A-21 5 9 16.2 2.700 4.501 No DR009A0270 3.5 40
VFD040C43A-21 5 10.5 18.9 2.315 3.858 No DR010A0231 4.5 50
VFD055C43A-21 7.5 12 21.6 2.025 3.375 No DR012A0202 4.8 50
VFD075C43A-21 10 18 32.4 1.174 1.957 No DR018A0117 5.3 54
VFD110C43A-21 15 24 43.2 0.881 1.468 No DR024AP881 5.8 60
VFD150C43A-21 20 32 57.6 0.66 1.101 No DR032AP660 9 80
VFD185C43A-21 25 38 68.4 0.639 1.066 No DR038AP639 9.5 85
VFD220C43A-21 30 45 81 0.541 0.900 No DR045AP541 10.5 95
VFD300C43A-21 40 60 108 0.405 0.675 No DR060AP405 11.5 100
VFD370C43S-00
VFD370C43S-21
50 73 131.4 0.334 0.555 Yes DR073AP334 25 115
Table 7-19
Table 7-20
