Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-19
Model HP
Rated
Current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Input AC
reactor
Delta part #
Weight
(kg)
Heat
Dissipation
(W)
VFD450C43S-00
VFD450C43S-21
60 91 163.8 0.267 0.445 Yes DR091AP267 25 130
VFD550C43A-00
VFD550C43A-21
75 110 198 0.221 0.368 Yes DR110AP221 28 150
VFD750C43A-00
VFD750C43A-21
100 150 270 0.162 0.270 Yes DR150AP162 35 170
VFD900C43A-00
VFD900C43A-21
125 180 324 0.135 0.225 Yes DR180AP135 42 190
VFD1100C43A-00
VFD1100C43A-21
150 220 396 0.110 0.184 Yes DR220AP110 45 230
VFD1320C43A-00
VFD1320C43A-21
175 260 468 0.098 0.162 Yes DR260AP098 55 280
VFD1600C43A-00
VFD1600C43A-21
215 310 558 0.078 0.131 Yes DR310AP078 60 300
VFD1850C43A-00
VFD1850C43A-21
250 370 666 0.066 0.109 Yes DR370AP066 75 340
VFD2000C43A-00
VFD2000C43A-21
270 395 474 0.061 0.1 Yes DR460AP054
*1
85 400
VFD2200C43A-00
VFD2200C43A-21
300 460 828 0.054 0.090 Yes DR460AP054 85 400
VFD2500C43A-00
VFD2500C43A-21
340 481 578 0.052 0.086 Yes DR550AP044
*1
95 430
VFD2800C43A-00
VFD2800C43C-21
375 550 990 0.044 0.074 Yes DR550AP044 95 430
VFD3150C43A-00
VFD3150C43C-21
420 616 1108.8 0.039 0.066 Yes DR616AP039 110 450
VFD3550C43A-00
VFD3550C43C-21
475 683 1229.4 0.036 0.060 Yes DR683AP036 130 480
VFD4000C43A-00
VFD4000C43A-21
530 770 924 0.028 0.047 Yes DR866AP028 170 610
VFD4500C43A-00
VFD4500C43C-21
600 866 1558.8 0.028 0.047 Yes DR866AP028 170 610
VFD5000C43A-00
VFD5000C43C-21
650 930 1674 0.026 0.044 Yes N/A N/A N/A
VFD5600C43A-00
VFD5600C43C-21
750 1094 1969.2 0.022 0.037 Yes N/A N/A N/A
.
Table 7-21
NOTE: *1: The inductance value for the above applications of Delta’s reactors will be close to, but less than 3%
380V–460V, 50/60 Hz / Super Heavy Duty
Model HP
Rated
Current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Input AC
reactor
Delta part #
Weight
(kg)
Heat
Dissipation
(W)
VFD007C43A-21 1 1.7 3.4 14.298 23.827 No N/A N/A N/A
VFD015C43A-21 2 3 6 8.102 13.502 No DR003A0810 1.5 20
VFD022C43A-21 3 4 8 6.077 10.127 No DR004A0607 1.8 21
VFD037C43A-21 5 6 12 4.05 6.752 No DR006A0405 2.8 31
VFD040C43A-21 5 9 18 2.7 4.501 No DR009A0270 3.5 40
VFD055C43A-21 7.5 10.5 21 2.315 3.858 No DR010A0231 4.5 50
VFD075C43A-21 10 12 24 2.025 3.375 No DR012A0202 4.8 50
VFD110C43A-21 15 18 36 1.174 1.957 No DR018A0117 5.3 54
VFD150C43A-21 20 24 48 0.881 1.468 No DR024AP881 5.8 60
VFD185C43A-21 25 32 64 0.66 1.101 No DR032AP660 9 80
VFD220C43A-21 30 38 76 0.639 1.066 No DR038AP639 9.5 85
VFD300C43A-21 40 45 90 0.541 0.9 No DR045AP541 10.5 95
VFD370C43S-00
VFD370C43S-21
50 60 120 0.405 0.675 Yes DR060AP405 11.5 100
VFD450C43S-00
VFD450C43S-21
60 73 146 0.334 0.555 Yes DR073AP334 25 115
VFD550C43A-00
VFD550C43A-21
75 91 182 0.267 0.445 Yes DR091AP267 25 130
