Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-37
Figure 7-22
Unit: mm
AC Input Reactors
Delta part #
A A1 B B1 B2 C C1 D1*D2 E G1 G2 H
M*T
DR460AP054 300 300 425
95 355
220
170
11*21 200 240 300 190
50*4
DR550AP044
300 300
445
95 375
220
170
11*21 200 240 300 190
50*4
DR616AP039
360 360
465
105 385
252
190
11*21 240 246 316 220
50*5
DR683AP036
360 360
465
105 385
252
195
11*21 240 246 316 220
50*5
DR866AP028
360 360
520
105 435
272
200
11*21 240 246 316 240
60*6
Table 7-40
PE Screw M8 x 23
Torque: 58.2–64.3 kg-cm /
(50.5–55.8 lb-in.) /
(5.7–6.3 Nm)
Terminals 4 mm
2
Torque: 8.2–10.2 kg-cm /
(7.1–8.9 lb-in.) /
(0.8–1.0 Nm)
