Chapter 7 Optional AccessoriesC2000 Plus
7-36
Figure 7-21
Unit: mm
AC Input Reactors
Delta part #
A A1 B B1 B2 C C1 D D1*D2 F G1 G2 H
M*T
DR150AP162 240
250
245
40 200
151
105 9
11*18 160 190 220 125
20*3
DR180AP135
240 250
245
40 200
151
105 9
11*18 160 190 220 125
20*3
DR220AP110
264 270
275
50 230
151
105 9
10*18 176 200 230 106
30*3
DR260AP098
264 270
285
50 240
151
105 9
10*18 176 200 230 106
30*3
DR310AP078
300 300
345
55 295
153
105 9
10*18 200 224 260 113
30*3
DR370AP066
300 300
345
55 295
158
120 9
10*18 200 224 260 118
50*4
Table 7-39
Terminals 4 mm
2
Torque: 8.2–10.2 kg-cm /
(7.1–8.9 lb-in.) /
(0.8–1.0 Nm)
PE Screw M8 x 23
Torque: 58.2–64.3 kg-cm /
(50.5–55.8 lb-in.) /
(5.7–6.3 Nm)
