Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-43
Model HP
Rated
current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Output AC
reactor Delta
part #
Weight
(kg)
Heat
Dissipation
(W)
VFD450C23A-00
VFD450C23A-21
60 180 324 0.070 0.117 Yes DR180LP070 26 125
VFD550C23A-00
VFD550C23A-21
75 215 387 0.059 0.098 Yes DR215LP059 30 150
VFD750C23A-00
VFD750C23A-21
100 255 459 0.049 0.083 Yes DR276LP049 37 210
VFD900C23A-00
VFD900C23A-21
125 346 622.8 0.037 0.061 Yes DR346LP037 40 220
200V–230V, 50/60 Hz / Super Heavy Duty
Model HP
Rated
current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Output AC
reactor Delta
part #
Weight
(kg)
Heat
Dissipation
(W)
VFD007C23A-21
1 3 6 4.227 7.045 No N/A
N/A
N/A
VFD015C23A-21
2 5 10 2.536 4.227 No DR005L0254
1.5
15
VFD022C23A-21
3 8 16 1.585 2.642 No DR008L0159
2.5
30
VFD037C23A-21
5 11 22 1.152 1.922 No DR011L0115
3.0
33
VFD055C23A-21
7.5 17 34 0.746 1.243 No DR017LP746
3.6
34
VFD075C23A-21
10 25 50 0.507 0.845 No DR025LP507
5.5
50
VFD110C23A-21
15 33 66 0.32 0.534 No DR033LP320
6.5
50
VFD150C23A-21
20 49 98 0.216 0.359 No DR049LP215
8.6
62
VFD185C23A-21
25 65 130 0.163 0.271 No DR065LP162
12
70
VFD220C23A-21
30 75 150 0.169 0.282 No DR075LP170
14.5
80
VFD300C23A-00
VFD300C23A-21
40 90 180 0.141 0.235 Yes DR090LP141
15
80
VFD370C23A-00
VFD370C23A-21
50 120 240 0.106 0.176 Yes DR146LP087
22
110
VFD450C23A-00
VFD450C23A-21
60 146 292 0.087 0.145 Yes DR146LP087
22
110
VFD550C23A-00
VFD550C23A-21
75 180 360 0.07 0.117 Yes DR180LP070
26
125
VFD750C23A-00
VFD750C23A-21
100 215 430 0.059 0.098 Yes DR215LP059
30
150
VFD900C23A-00
VFD900C23A-21
125 255 510 0.049 0.083 Yes DR276LP049
37
210
380V–460V, 50/60 Hz / Heavy Duty
Model HP
Rated
current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Output AC
reactor Delta
part #
Weight
(kg)
Heat
Dissipation
(W)
VFD007C43A-21 1 3 5.4 8.102 13.502 No DR003L0810 1.5 13
VFD015C43A-21 2 4 7.2 6.077 10.127 No DR004L0607 2.5 18
VFD022C43A-21 3 6 10.8 4.050 6.752 No DR006L0405 3.0 22
VFD037C43A-21 5 9 16.2 2.700 4.501 No DR009L0270 3.6 35
VFD040C43A-21 5 10.5 18.9 2.315 3.858 No DR010L0231 5.5 40
VFD055C43A-21 7.5 12 21.6 2.025 3.375 No DR012L0202 6.0 45
Table 7-48
Table 7-49
