Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-44
Model HP
Rated
current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Output AC
reactor Delta
part #
Weight
(kg)
Heat
Dissipation
(W)
VFD075C43A-21 10 18 32.4 1.174 1.957 No DR018L0117 6.4 48
VFD110C43A-21 15 24 43.2 0.881 1.468 No DR024LP881 7.2 52
VFD150C43A-21 20 32 57.6 0.66 1.101 No DR032LP660 11 66
VFD185C43A-21 25 38 68.4 0.639 1.066 No DR038LP639 12 70
VFD220C43A-21 30 45 81 0.541 0.900 No DR045LP541 16 85
VFD300C43A-21 40 60 108 0.405 0.675 No DR060LP405 18 85
VFD370C43S-00
VFD370C43S-21
50 73 131.4 0.334 0.555 Yes DR073LP334 25 110
VFD450C43S-00
VFD450C43S-21
60 91 163.8 0.267 0.445 Yes DR091LP267 25 130
VFD550C43A-00
VFD550C43A-21
75 110 198 0.221 0.368 Yes DR110LP221 28 150
VFD750C43A-00
VFD750C43A-21
100 150 270 0.162 0.270 Yes DR150LP162 35 175
VFD900C43A-00
VFD900C43A-21
125 180 324 0.135 0.225 Yes DR180LP135 42 195
VFD1100C43A-00
VFD1100C43A-21
150 220 396 0.110 0.184 Yes DR220LP110 45 235
VFD1320C43A-00
VFD1320C43A-21
175 260 468 0.098 0.162 Yes DR260LP098 55 285
VFD1600C43A-00
VFD1600C43A-21
215 310 558 0.078 0.131 Yes DR310LP078 60 300
VFD1850C43A-00
VFD1850C43A-21
250 370 666 0.066 0.109 Yes DR370LP066 75 345
VFD2000C43A-00
VFD2000C43A-21
270 395 474 0.061 0.1 Yes
DR370LP066
*1
75 410
VFD2200C43A-00
VFD2200C43A-21
300 460 828 0.054 0.090 Yes DR460LP054 85 410
VFD2500C43A-00
VFD2500C43A-21
340 481 578 0.052 0.086 Yes
DR460LP054
*1
85 440
VFD2800C43A-00
VFD2800C43C-21
375 550 990 0.044 0.074 Yes DR550LP044 95 440
VFD3150C43A-00
VFD3150C43C-21
420 616 1108.8 0.039 0.066 Yes DR616LP039 110 465
VFD3550C43A-00
VFD3550C43C-21
475 683 1229.4 0.036 0.060 Yes DR683LP036 130 495
VFD4000C43A-00
VFD4000C43A-21
536 770 924 0.028 0.047 Yes DR866LP028 170 600
VFD4500C43A-00
VFD4500C43C-21
600 866 1558.8 0.028 0.047 Yes DR866LP028 170 600
VFD5000C43A-00
VFD5000C43C-21
650 930 1674 0.026 0.044 Yes N/A N/A N/A
VFD5600C43A-00
VFD5600C43C-21
750 1094 1969.2 0.022 0.037 Yes N/A N/A N/A
Table 7-50
NOTE: *1: The inductance value for the above applications of Delta’s reactors will be close to, but less than 3%.
