Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-45
380V–460V, 50/60 Hz / Super Heavy Duty
Model HP
Rated
current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Output AC
reactor Delta
part #
Weight
(kg)
Heat
Dissipation
(W)
VFD007C43A-21 1 1.7 3.4 14.298 23.827 No N/A
N/A
N/A
VFD015C43A-21 2 3 6 8.102 13.502 No DR003L0810
1.5
13
VFD022C43A-21 3 4 8 6.077 10.127 No DR004L0607
2.5
18
VFD037C43A-21 5 6 12 4.05 6.752 No DR006L0405
3.0
22
VFD040C43A-21 5 9 18 2.7 4.501 No DR009L0270
3.6
35
VFD055C43A-21 7.5 10.5 21 2.315 3.858 No DR010L0231
5.5
40
VFD075C43A-21 10 12 24 2.025 3.375 No DR012L0202
6.0
45
VFD110C43A-21 15 18 36 1.174 1.957 No DR018L0117
6.4
48
VFD150C43A-21 20 24 48 0.881 1.468 No DR024LP881
7.2
52
VFD185C43A-21 25 32 64 0.66 1.101 No DR032LP660
11
66
VFD220C43A-21 30 38 76 0.639 1.066 No DR038LP639
12
70
VFD300C43A-21 40 45 90 0.541 0.9 No DR045LP541
16
85
VFD370C43S-00
VFD370C43S-21
50 60 120 0.405 0.675 Yes DR060LP405
18
85
VFD450C43S-00
VFD450C43S-21
60 73 146 0.334 0.555 Yes DR073LP334
25
110
VFD550C43A-00
VFD550C43A-21
75 91 182 0.267 0.445 Yes DR091LP267
25
130
VFD750C43A-00
VFD750C43A-21
100 110 220 0.221 0.368 Yes DR110LP221
28
150
VFD900C43A-00
VFD900C43A-21
125 150 300 0.162 0.27 Yes DR150LP162
35
175
VFD1100C43A-00
VFD1100C43A-21
150 180 360 0.135 0.225 Yes DR180LP135
42
195
VFD1320C43A-00
VFD1320C43A-21
175 220 440 0.11 0.184 Yes DR220LP110
45
235
VFD1600C43A-00
VFD1600C43A-21
215 260 520 0.098 0.162 Yes DR260LP098
55
285
VFD1850C43A-00
VFD1850C43A-21
250 310 620 0.078 0.131 Yes DR310LP078
60
300
VFD2000C43A-00
VFD2000C43A-21
270 335 536 0.072 0.12 Yes
DR370LP066
*1
75
345
VFD2200C43A-00
VFD2200C43A-21
300 370 740 0.066 0.109 Yes DR370LP066
75
345
VFD2500C43A-00
VFD2500C43A-21
340 415 664 0.058 0.10 Yes
DR460LP054
*1
85
410
VFD2800C43A-00
VFD2800C43C-21
375 460 920 0.054 0.09 Yes DR460LP054
85
410
VFD3150C43A-00
VFD3150C43C-21
420 550 1100 0.044 0.074 Yes DR550LP044
95
440
VFD3550C43A-00
VFD3550C43C-21
475 616 1232 0.039 0.066 Yes DR616LP039
110
465
VFD4000C43A-00
VFD4000C43A-21
530 683 1092.8 0.036 0.06 Yes DR683LP036
130
495
