Chapter 7 Optional AccessoriesC2000 Plus
7-46
Model HP
Rated
current
(Arms)
Saturation
current
(Arms)
3%
impedance
(mH)
5%
impedance
(mH)
Built-in
DC
reactor
Output AC
reactor Delta
part #
Weight
(kg)
Heat
Dissipation
(W)
VFD4500C43A-00
VFD4500C43C-21
600 683 1366 0.036 0.06 Yes DR683LP036
170
495
VFD5000C43A-00
VFD5000C43C-21
650 866 1732 0.028 0.047 Yes DR866LP028
95
600
VFD5600C43A-00
VFD5600C43C-21
750 930 1860 0.026 0.044 Yes N/A
N/A
N/A
Table 7-51
NOTE: *1: The inductance value for the above applications of Delta’s reactors will be close to, but less than 3%.
575V, 50/60 Hz, Three-phase
Model HP
Rated current (Arms)
Saturation
current (Arms)
3% impedance (mH) 5% impedance (mH)
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
VFD015C53A-21 2 3 2.5 2.1 4.2 8.806 10.567 12.580 14.677 17.612 20.967
VFD022C531-21 3 4.3 3.6 3 5.9 6.144 7.338 8.806 10.239 12.230 14.677
VFD037C53A-21 5 6.7 5.5 4.6 9.1 3.943 4.803 5.743 6.572 8.005 9.572
VFD055C53A-21 7.5 9.9 8.2 6.9 13.7 2.668 3.222 3.829 4.447 5.369 6.381
VFD075C53A-21 10 12.1 10 8.3 16.5 2.183 2.642 3.183 3.639 4.403 5.305
VFD110C53A-21 15 18.7 15.5 13 25.7 1.413 1.704 2.032 2.355 2.841 3.387
VFD150C53A-21 20 24.2 20 16.8 33.3 1.092 1.321 1.572 1.819 2.201 2.621
690V, 50/60 Hz, Three-phase
Model HP
Rated current Saturation current 3% impedance 5% impedance
(Arms) (Arms) (mH) (mH)
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
VFD185C63B-21 25 24 20 14 28.8 30.0 25.2 1.585 1.902 2.717 2.642 3.170 4.529
VFD220C63B-21 30 30 24 20 36.0 36.0 36.0 1.268 1.585 1.902 2.113 2.642 3.170
VFD300C63B-21 40 36 30 24 43.2 45.0 43.2 1.057 1.268 1.585 1.761 2.113 2.642
VFD370C63B-21 50 45 36 30 54.0 54.0 54.0 0.845 1.057 1.268 1.409 1.761 2.113
VFD450C63B-00
VFD450C63B-21
60 54 45 36 64.8 67.5 64.8 0.704 0.845 1.057 1.174 1.409 1.761
VFD550C63B-00
VFD550C63B-21
75 67 54 45 80.4 81.0 81.0 0.568 0.704 0.845 0.946 1.174 1.409
VFD750C63B-00
VFD750C63B-21
100 86 67 54 103.2 100.5 97.2 0.442 0.568 0.704 0.737 0.946 1.174
VFD900C63B-00
VFD900C63B-21
125 104 86 67 124.8 129.0 120.6 0.366 0.442 0.568 0.610 0.737 0.946
VFD1100C63B-00
VFD1100C63B-21
150 125 104 86 150.0 156.0 154.8 0.304 0.366 0.442 0.507 0.610 0.737
VFD1320C63B-00
VFD1320C63B-21
175 150 125 104 180.0 187.5 187.2 0.254 0.304 0.366 0.423 0.507 0.610
VFD1600C63B-00
VFD1600C63B-21
215 180 150 125 216.0 225.0 225.0 0.211 0.254 0.304 0.352 0.423 0.507
VFD2000C63B-00
VFD2000C63B-21
270 220 180 150 264.0 270.0 270.0 0.173 0.211 0.254 0.288 0.352 0.423
Table 7-52
