Delta VFD040C43A-21 User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-47
Model HP
Rated current Saturation current 3% impedance 5% impedance
(Arms) (Arms) (mH) (mH)
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
Light
load
Normal
load
Heavy
load
VFD2500C63B-00
VFD2500C63B-21
335 290 220 180 348.0 330.0 324.0 0.131 0.173 0.211 0.219 0.288 0.352
VFD3150C63B-00
VFD3150C63B-21
425 350 290 220 420.0 435.0 396.0 0.109 0.131 0.173 0.181 0.219 0.288
VFD4000C63B-00
VFD4000C63B-21
530 430 350 290 516.0 525.0 522.0 0.088 0.109 0.131 0.147 0.181 0.219
VFD4500C63B-00
VFD4500C63B-21
600 465 385 310 558.0 577.5 558.0 0.082 0.099 0.123 0.136 0.165 0.205
VFD5600C63B-00
VFD5600C63B-21
745 590 465 420 708.0 697.5 756.0 0.064 0.082 0.091 0.107 0.136 0.151
VFD6300C63B-00
VFD6300C63B-21
850 675 675 675 810.0 1012.5 1215.0 0.056 0.056 0.056 0.094 0.094 0.094
Table 7-53
