Chapter 7 Optional AccessoriesC2000 Plus
7-119
Frame C
Model “MKC-CFKB1” Capacitor Fan
Applicable models
VFD150C23A-21; VFD185C23A-21; VFD220C23A-21
Model “MKC-CFKB2” Capacitor Fan
Applicable models
VFD185C43A-21; VFD220C43A-21; VFD300C43A-21; VFD185C4EA-21; VFD220C4EA-21; VFD300C4EA-21
Model “MKC-CFKB3” Capacitor Fan
Applicable models
VFD185C63B-21; VFD220C63B-21; VFD300C63B-21; VFD370C63B-21
Disconnect fan power and pull out the fan by using a flat-head screwdriver. (As shown in the enlarged picture)
Figure 7-156
Disconnect fan power and pull out the
fan by a flat-head screwdriver.
Pay attention to direction of the
latch during the installation.
To Next Page
