Delta VFD040C43A-21 User Manual

Chapter 9 Specification C2000 Plus
9-2
9-1 230V Models
Frame Size A B C D E F
VFD _ _ _C23A-00 / -21
007 015 022 037 055 075 110 150 185 220 300 370 450 550 750 900
Output Rating*
Heavy duty
Rated Output Capacity (kVA)
2.0 3.2 4.4 6.8 10 13 20 26 30 36 48 58 72 86 102 138
Rated Output Current (A)
5 8 11 17 25 33 49 65 75 90 120 146 180 215 255 346
Applicable Motor Output (kW)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90
Applicable Motor Output (HP)
1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
180% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–15 (Default: 8) 2–10 (Default: 6) 2–9 (Default: 4)
Super Heavy Duty
Rated Output Capacity (kVA)
1.2 2 3.2 4.4 6.8 10 13 20 26 30 36 48 58 72 86 102
Rated Output Current (A)
3 5 8 11 17 25 33 49 65 75 90 120 146 180 215 255
Applicable Motor Output (kW)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 19 22 30 37 45 55 75
Applicable Motor Output (HP)
0.5 1 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
200% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–15 (Default: 4) 2–10 (Default: 4) 2–9 (Default: 4)
Input Rating
Input Current
(A)
Heavy Duty 6.4 12 16 20 28 36 52 72 83 99 124 143 171 206 245 331
Super Heavy Duty 3.9 6.4 12 16 20 28 36 52 72 83 99 124 143 171 206 245
Rated Voltage / Frequency
3-phase AC 200–240V (-15 % – +10 %), 50 / 60 Hz
Operating Voltage Range
170–264 V
AC
Frequency Tolerance
47–63 Hz
Power Supply
Capacity (kVA)
Heavy Duty
2.7 5.0 6.7 8.3 11.6 15.0 21.6 29.9 34.5 41.2 51.5 59.4 71.1 85.6 101.8 137.6
Super Heavy Duty
1.6 2.7 5.0 6.7 8.3 11.6 15.0 21.6 29.9 34.5 41.2 51.5 59.4 71.1 85.6 101.8
Efficiency (%)
97.8 98.2
Displacement Power Factor (cosθ)
>0.98
Weight (Kg)
2.6 ± 0.3 5.4 ± 1 9.8 ± 1.5 38.5 ± 1.5 64.8 ± 1.5 86.5 ± 1.5
Cooling Method
Natural
cooling
Fan cooling
Braking Chopper
Frame A–C: Built-in Frame D–F: Optional
DC choke
Frame A–C: Optional Frame D–F: Built-in
EMC Filter
Frame A~F: Optional
EMC-COP01
Frame A~F: Optional
Table 9-1
NOTE:
1. * : The default is heavy duty mode.
2. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section
9-7 Derating Curve for details.
3. The AC motor drive should operate in derating current when its control method is set to FOC Sensorless,
TQC+PG, TQC sensorless. PM+PG, PM sensorless Refer to Pr.06-55 for more information.
4. The rated input current will be affected by not only power transformer and the connection of the reactors on input
side, but also fluctuates with the impedance of power side.
5. Rated output capacity is calculated by 460 V
AC
, it is as a reference for the mains power drive capacity selection.
