Delta VFD040C43A-21 User Manual

Chapter 9 Specification C2000 Plus
9-3
9-2 460V Models
Frame Size A B C
VFD _ _ _ C_ _ -00 / -21
007 015 022 037 040 055 075 110 150 185 220 300
Output Rating*
Heavy duty
Rated Output Capacity (kVA)
2.4 3.2 4.8 7.2 8.4 10 14 19 25 30 36 48
Rated Output Current (A)
3.0 4.0 6.0 9.0 10.5 12 18 24 32 38 45 60
Applicable Motor Output (kW)
0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5 22 30
Applicable Motor Output (HP)
1 2 3 5 5 7.5 10 15 20 25 30 40
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
180% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–15 (Default: 8) 2–10 (Default: 6)
Super Heavy Duty
Rated Output Capacity (kVA)
1.4 2.4 3.2 4.8 7.2 8.4 9.6 14 19 25 30 36
Rated Output Current (A)
1.7 3 4 6 9 10.5 12 18 24 32 38 45
Applicable Motor Output (kW)
0.4 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5 22
Applicable Motor Output (HP)
0.5 1 2 3 5 5 7.5 10 15 20 25 30
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
200% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–15 (Default: 4) 2–10 (Default: 4)
Input Rating
Input Current
(A)
Heavy Duty 4.3 5.9 8.7 14 15.5 17 20 26 35 40 47 63
Super Heavy Duty 3.5 4.3 5.9 8.7 14 15.5 17 20 26 35 40 47
Rated Voltage / Frequency
3-phase AC 380–480V (-15 % – +10 %), 50 / 60 Hz
Operating Voltage Range
323–528 V
AC
Frequency Tolerance
47–63 Hz
Power Supply
Capacity (kVA)
Heavy Duty
3.6 4.9 7.2 11.6 12.9 14.1 16.6 21.6 29.1 33.3 39.1 52.4
Super Heavy Duty 2.9 3.6 4.9 7.2 11.6 12.9 14.1 16.6 21.6 29.1 33.3 39.1
Efficiency (%)
97.8
Displacement Power Factor (cosθ)
>0.98
Drive Weight (Kg)
2.6± 0.3 5.4± 1 9.8± 1.5
Cooling Method
Natural
cooling
Fan cooling
Braking Chopper
Frame A–C: Built-in
DC choke
Frame A–C: Optional
EMC Filter
Frame A–C (VFDxxxC43A-21): Optional
Frame A–C (VFDxxxC4EA-21): Built-in
EMC-COP01
Frame A–C (VFDxxxC43A-21): Optional
Frame A–C (VFDxxxC4EA-21): Built-in
Table 9-2
NOTE:
1. * : The factory setting is heavy duty mode.
2. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section
9-7 Derating Curve for details.
3. The AC motor drive should operate in derating current when its control method is set to FOC Sensorless,
TQC+PG, TQC sensorless. PM+PG, PM sensorless. Refer to Pr. 06-55 for more information.
4. The rated input current will be affected by not only power transformer and the connection of the reactors on input
side, but also fluctuates with the impedance of power side.
5. Rated output capacity is calculated by 460 V
AC
, it is as a reference for the mains power drive capacity selection.
