Delta VFD040C43A-21 User Manual

Chapter 9 Specification C2000 Plus
9-4
Frame Size D0 D E F
VFD-_ _ _ C_ _ _-21 / -00
370 450 550 750 900 1100 1320 1600
Output Rating*
Heavy duty
Rated Output Capacity (kVA)
58 73 88 120 143 175 207 247
Rated Output Current (A)
73 91 110 150 180 220 260 310
Applicable Motor Output (kW)
37 45 55 75 90 110 132 160
Applicable Motor Output (HP)
50 60 75 100 125 150 175 215
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
180% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–10 (Default: 6) 2–9 (Default: 4)
Super Heavy Duty
Rated Output Capacity (kVA)
48 58 73 88 120 143 175 207
Rated Output Current (A)
60 73 91 110 150 180 220 260
Applicable Motor Output (kW)
30 37 45 55 75 90 110 132
Applicable Motor Output (HP)
40 50 60 75 100 125 150 175
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
200% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–10 (Default: 4) 2–9 (Default: 4)
Input Rating
Input Current
(A)
Heavy Duty 74 101 114 157 167 207 240 300
Super Heavy Duty 63 74 101 114 157 167 207 240
Rated Voltage / Frequency
3-phase AC 380–480V (-15 % – +10 %), 50 / 60 Hz
Operating Voltage Range
323–528 V
AC
Frequency Tolerance
47–63 Hz
Power Supply
Capacity (kVA)
Heavy Duty
61.5 84.0 94.8 130.5 138.8 172.1 199.5 249.4
Super Heavy Duty 52.4 61.5 84.0 94.8 130.5 138.8 172.1 199.5
Efficiency (%)
97.8 98.2
Displacement Power Factor (cosθ)
>0.98
Drive Weight (Kg)
27 ± 1.5 38.5 ± 1.5 64.8 ± 1.5 86.5 ± 1.5
Cooling Method
Fan cooling
Braking Chopper
Frame D0–F: Optional
DC choke Frame D0–F: Built-in
EMC Filter Frame D0–F: Optional
EMC-COP01
Frame D0–F (VFDxxxC43A-00): Optional
Frame D0–F (VFDxxxC43A-21): Built-in
Table 9-3
NOTE:
1. * : The factory setting is heavy duty mode.
2. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section
9-7 Derating Curve for details.
3. The AC motor drive should operate in derating current when its control method is set to FOC Sensorless,
TQC+PG, TQC sensorless. PM+PG, PM sensorless Please refer to Pr. 06-55 for more information.
4. The rated input current will be affected by not only power transformer and the connection of the reactors on input
side, but also fluctuates with the impedance of power side.
5. Rated output capacity is calculated by 460 V
AC
, it is as a reference for the mains power drive capacity selection.
