Chapter 9 Specification C2000 Plus
9-6
9-3 575V Models
Frame Size A B
VFD-_ _ _ C53A-21
015 022 037 055 075 110 150
*Output Rating
Light Duty
Rated Output Capacity (kVA)
3 4.3 6.7 9.9 12.1 18.6 24.1
Rated Output Current (A)
3 4.3 6.7 9.9 12.1 18.7 24.2
Applicable Motor Output (kW)
1.5 2.2 3.7 5.5 7.5 11 15
Applicable Motor Output (HP)
2 3 5 7.5 10 15 20
Normal Duty
Rated Output Capacity (kVA)
2.5 3.6 5.5 8.2 10 15.4 19.9
Rated Output Current (A)
2.5 3.6 5.5 8.2 10 15.5 20
Applicable Motor Output (kW)
0.75 1.5 2.2 3.7 5.5 7.5 11
Applicable Motor Output (HP)
1 2 3 5 7.5 10 15
Heavy Duty
Rated Output Capacity (kVA)
2.1 3 4.6 6.9 8.3 12.9 16.7
Rated Output Current (A)
2.1 3 4.6 6.9 8.3 13 16.8
Applicable Motor Output (kW)
0.75 1.5 2.2 3.7 3.7 7.5 7.5
Applicable Motor Output (HP)
1 2 3 5 5 10 10
Max. Output Frequency (Hz) 0.00–599.00
Carrier Frequency (kHz) 2–15 (Default: 4)
Input Rating
Input Current
(A)
Light Duty
3.8 5.4 10.4 14.9 16.9 21.3 26.3
Normal Duty
3.1 4.5 7.2 12.3 15 18 22.8
Heavy Duty
2.6 3.8 5.8 10.7 12.5 16.9 19.7
Rated Voltage / Frequency 3-phase AC 525–600 V ( -15% – +10%), 50 / 60 Hz
Operating Voltage Range 446–660 V
AC
Frequency Tolerance 47–63Hz
Power Supply
Capacity (kVA)
Light Duty
3.9 5.6 10.8 15.5 17.6 22.1 27.3
Normal Duty
3.2 4.7 7.5 12.8 15.6 18.7 23.7
Heavy Duty
2.7 3.9 6.0 11.1 13.0 17.6 20.5
Efficiency (%) 97 98
Displacement Power Factor (cosθ) >0.98
Drive Weight (Kg) 3 ± 0.3 4.8 ± 1
Cooling Method Natural cooling Fan cooling
Braking Chopper Frame A~B: Built-in
DC choke Frame A~B: Optional
EMC Filter Frame A~B: Optional
Table 9-5
NOTE:
1. * Pr.00-16; available duty modes: Light Duty (LD), Normal Duty (ND) and Heavy Duty (HD); default setting is LD
mode
2. Rated output capacity is calculated by 460 V
AC
, it is as a reference for the mains power drive capacity selection.
