Delta VFD040C43A-21 User Manual

Chapter 9 Specification C2000 Plus
9-7
9-4 690V Models
Frame Size C D E
VFD-_ _ _ C63B-00 / -21
185 220 300 370 450 550 750 900 1100 1320
*Output Rating
Light Duty
Rated Output Capacity (kVA)
29 36 43 54 65 80 103 124 149 179
Applicable Motor Output (690V, kW)
18.5 22 30 37 45 55 75 90 110 132
Applicable Motor Output (690V, HP)
25 30 40 50 60 75 100 125 150 175
Applicable Motor Output (575V, HP)
20 25 30 40 50 60 75 100 125 150
Rated Output Current (A)
24 30 36 45 54 67 86 104 125 150
Normal Duty
Rated Output Capacity (kVA)
24 29 36 43 54 65 80 103 124 149
Applicable Motor Output (690V, kW)
15 18.5 22 30 37 45 55 75 90 110
Applicable Motor Output (690V, HP)
20 25 30 40 50 60 75 100 125 150
Applicable Motor Output (575V, HP)
15 20 25 30 40 50 60 75 100 125
Rated Output Current (A)
20 24 30 36 45 54 67 86 104 125
Heavy Duty
Rated Output Capacity (kVA)
17 24 29 36 43 54 65 80 103 124
Applicable Motor Output (690V, kW)
11 15 18.5 22 30 37 45 55 75 90
Applicable Motor Output (690V, HP)
15 20 25 30 40 50 60 75 100 125
Applicable Motor Output (575V, HP)
10 15 20 25 30 40 50 60 75 100
Rated Output Current (A)
14 20 24 30 36 45 54 67 86 104
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–9 (Default: 4)
Input Rating
Input Current (A)
Light Duty
29 36 43 54 65 81 84 102 122 147
Normal Duty
24 29 36 43 54 65 66 84 102 122
Heavy Duty
20 24 29 36 43 54 53 66 84 102
Rated Voltage / Frequency 3-phase AC 525–690 V ( -15% – +10%), 50 / 60 Hz
Operating Voltage Range 446–759 V
AC
Frequency Tolerance 47–63Hz
Power Supply
Capacity (kVA)
Light Duty
34.7 43.0 51.4 64.5 77.7 96.8 100.4 121.9 145.8 175.7
Normal Duty
28.7 34.7 43.0 51.4 64.5 77.7 78.9 100.4 121.9 145.8
Heavy Duty
23.9 28.7 34.7 43.0 51.4 64.5 63.3 78.9 100.4 121.9
Efficiency (%) 97
Displacement Power Factor (cosθ) >0.98
Drive Weight (Kg) 10 ± 1.5 39 ± 1.5 61 ± 1.5
Cooling Method Fan cooling
Braking Chopper Frame C: Built-in Frame D–E: Optional
DC choke Frame C: Optional Frame D–E: Built-in
EMC Filter Frame C–E: Optional
Table 9-6
NOTE:
1. * Pr.00-16; available duty modes: Light Duty (LD), Normal Duty (ND) and Heavy Duty (HD); default setting is LD
mode
2. Rated output capacity is calculated by 460 V
AC
, it is as a reference for the mains power drive capacity selection.
