Chapter 10 Digital KeypadC2000 Plus
10-15
Press ENTER to confirm the Time Setup.
NOTE:
Limitation: The charging process for the keypad super capacitor finishes in
about 6 minutes. When the digital keypad is removed, the time setting is
saved for 7 days. After 7 days, you must reset the time.
9. Keypad Locked
Press ENTER to lock
Lock the keypad
Use this function to lock the keypad. The main screen does not display
“keypad locked” when the keypad is locked; however, it displays the message
“Press ESC 3 sec to UnLock Key” when you press any key.
When the keypad is locked, the main screen does not
indicate the lock status.
Press any key on the keypad; a message displays as
shown on the left.
If you do not press the ESC key, the keypad
automatically returns to this screen.
Press any key on the keypad, a message displays as
shown on the left.
Press ESC for 3 seconds to unlock the keypad; the
keypad returns to this screen. All keys on the keypad
is functional.
All keys on the keypad is functional. Turning the power off and on does not
lock the keypad.
10. PLC Function
Press the UP / DOWN keys to
select a PLC function, and
then press ENTER.
When activating and stopping the PLC function (choosing 2: PLC Run or 3:
PLC Stop), the PLC status displays on main screen (Delta default setting).
Choose option 2: PLC Run to enable the PLC
function.
The default on the main screen displays the PLC /
RUN status message.
Choose option 3: PLC Stop to disable the PLC
function.
The default on the main screen displays the PLC /
STOP status message.
