Chapter 11 Summary of Parameter SettingsC2000 Plus
11-15
02 Digital Input / Output Parameters
Pr. Parameter Name Setting Range Default
02-00
Two-Wire / Three-Wire Operation
Control
0: Two-wire mode 1, power on for operation
control
1: Two-wire mode 2, power on for operation
control
2: Three-wire, power on for operation control
7: Single-wire mode, the Servo ON terminal under
position control mode (only the FWD terminal is
valid)
0
02-01
Multi-Function Input Command 1
(MI1)
0: No function
1: Multi-step speed command 1 / multi-step
position command 1
2: Multi-step speed command 2 / multi-step
position command 2
3: Multi-step speed command 3 / multi-step
position command 3
4: Multi-step speed command 4 / multi-step
position command 4
5: Reset
6: JOG operation (by external control or KPC-
CC01)
7: Acceleration / deceleration speed inhibit
8: 1
st
and 2
nd
acceleration / deceleration time
selection
9: 3
rd
and 4
th
acceleration / deceleration time
selection
10: External Fault (EF) input (Pr.07-20)
11: Base Block (B.B) input from external
12: Output voltage stops
13: Cancel the setting of auto-acceleration / auto-
deceleration time
14: Switch between motor 1 and motor 2
15: Rotating speed command from AVI
16: Rotating speed command from ACI
17: Rotating speed command from AUI
18: Forced to stop (Pr.07-20)
19: Frequency up command
20: Frequency down command
21: PID function disabled
22: Clear the counter
23: Input the counter value (MI6)
1
02-02
Multi-Function Input Command 2
(MI2)
2
02-03
Multi-Function Input Command 3
(MI3)
3
02-04
Multi-Function Input Command 4
(MI4)
4
02-05
Multi-Function Input Command 5
(MI5)
0
02-06
Multi-Function Input Command 6
(MI6)
0
02-07
Multi-Function Input Command 7
(MI7)
0
02-08
Multi-Function Input Command 8
(MI8)
0
02-26
Input Terminal of I/O Extension Card
(MI10)
0
02-27
Input Terminal of I/O Extension Card
(MI11)
0
02-28
Input Terminal of I/O Extension Card
(MI12)
0
02-29
Input Terminal of I/O Extension Card
(MI13)
0
02-30
Input Terminal of I/O Extension Card
(MI14)
0
02-31
Input Terminal of I/O Extension Card
(MI15)
0
