Delta VFD055ED43S

Chapter 11 Summary of Parameter Settings | VFD-ED
11-28
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
 07-20 Torque Offset Setting
0.0–100.0% (motor drive rated
torque)
0.0 ○ ○ ○
 07-21 High Torque Offset
0.0–100.0% (motor drive rated
torque)
30.0 ○ ○ ○
 07-22 Middle Torque Offset
0.0–100.0% (motor drive rated
torque)
20.0 ○ ○ ○
 07-23 Low Torque Offset
0.0–100.0% (motor drive rated
torque)
10.0 ○ ○ ○

07-24
Forward Motor Torque Limit
0–300% (motor drive rated torque)
200
○
○
 07-25
Forward Regenerative
Torque Limit
0–300% (motor drive rated torque) 200 ○ ○

07-26
Reverse Motor Torque Limit
0–300% (motor drive rated torque)
200
○
○
 07-27
Reverse Regenerative
Torque Limit
0–300% (motor drive rated torque) 200 ○ ○
 07-28
Emergency Stop (EF) &
Forced Stop
0: Coast to stop
1: According to deceleration time 1
2: According to deceleration time 2
3: According to deceleration time 3
4: According to deceleration time 4
5: According to Pr.01-31
0 ○ ○ ○ ○ ○
 07-29
Time for Decreasing Torque
at Stop
0.000–5.000 sec. 0.000 ○ ○
 07-30
DC Brake Current Level at
Stop
0–100% (motor drive rated current) 0 ○ ○ ○

07-31
Drive Output Torque
0.0–300.0%
0.0
○
○
○
○
○
07-32 Brake Torque Test Function
0: No function
1: Brake torque test
0 ○ ○ ○ ○ ○
07-33
Brake Torque Test Distance
0–65535 ppr
0
○
○
○
○
○
07-34
Brake Torque Test Time
0.0–5.0 sec.
5.0
○
○
○
○
○
07-35
Most Recent Output Torque
Ratio before Brake Torque
Test Failure
0.00–3.00
Read
only
○ ○ ○ ○ ○
 07-36
Minimum Output Torque
Ratio Allowed during Brake
Torque Test
0.00–2.00 0.00 ○ ○ ○ ○ ○
 07-37
Maximum Output Torque
Ratio Allowed during Brake
Torque Test
0.00–2.00 0.00 ○ ○ ○ ○ ○
