Chapter 11 Summary of Parameter Settings | VFD-ED
11-29
08 PM Parameters
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
08-00 Motor Auto-tuning
0: No function
1: Only for an unloaded motor,
auto-measures the angle
between magnetic pole and PG
origin (Pr.08-09)
2: For PM parameters (suggested
to lock the brake)
3: Auto-measures the angle
between magnetic pole and PG
origin (Pr.08-09)
0 ○
08-01
Motor Rated Current
(40–120%) * Pr.00-01 Amps
#.##
○
08-02
Motor Rated Power
0.00–655.35 kW
#.##
○
08-03
Motor Rated Speed (rpm)
0–65535 rpm
1710
○
08-04
Number of Motor Poles
2–96
4
○
08-05
Motor Rs
0.000–65.535
Ω
0.000
○
08-06
Motor Ld
0.0–6553.5 mH
0.0
○
08-07
Motor Lq
0.0–6553.5 mH
0.0
○
08-08
Back Electromotive Force
0.0–6553.5 V rms
0.0
○
08-09
Angle between Magnetic
Pole and PG Origin
0.0–360.0° 360.0
○
08-10
Magnetic Pole
Reorientation
0: Disable
1: Enable
0
○
