Chapter 12 Descriptions of Parameter Settings | VFD-ED
12-00-2
00 Drive Parameters
: You can set this parameter during operation
AC Motor Drive Identity Code
Control Mode VF VFPG SVC FOCPG FOCPM Default: ##
Settings Read Only
AC Motor Drive Rated Current Display
Control Mode VF VFPG SVC FOCPG FOCPM Default: ##
Settings Read Only (Display by model)
 Pr.00-00 displays the AC motor drive identity code. The capacity, rated current, rated voltage and the
maximum carrier frequency relate to the identity code. Use the following table to check how the AC motor
drive rated current, rated voltage, and maximum carrier frequency correspond to the identity code.
 Pr.00-01 displays the AC motor drive rated current. By reading this parameter, you can check if the AC
motor drive is correct.
230V models
Power (kW)
2.2* 3.7* 4.0 5.5 7.5 11 15 18.5 22 30 37
Horsepower (HP)
3 5 5 7.5 10 15 20 25 30 40 50
Motor Drive ID Code
(Pr.00-00)
108 110 10 12 14 16 18 20 22 24 26
Rated Output
Current for
General
Purposes (A)
12.0 17.0 20 24 30 45 58 77 87 132 161
Range of the
Carrier Frequency
2–15 kHz 2–9 kHz
Rated Max. Output
Carrier Frequency
8 kHz 10 kHz 8 kHz 6 kHz
*VFD022ED21S and VFD037ED21S are single-phase models.
460V models
Power (kW)
4.0
5.5
7.5
11
15
18.5
22
30
37
45
55
75
Horsepower (HP)
5
7.5
10
15
20
25
30
40
50
60
75
100
Motor Drive ID Code
(Pr.00-00)
11 13 15 17 19 21 23 25 27 29 31 33
Rated Output
Current for
General
Purposes (A)
11.5 13 17 23 30 38 45 58 80 100 128 165
Range of the
Carrier Frequency
2–15 kHz 2–9 kHz 2–6 kHz
Rated Max. Output
Carrier Frequency
8 kHz 10 kHz 8 kHz 6 kHz
