12 Descriptions of Parameter Settings | VFD-ED
14: Brake transistor signal
○ ○ ○ ○ ○
15: Motor-controlled magnetic contactor output
○ ○ ○ ○ ○
16: Slip error (oSL)
○ ○ ○ ○ ○
17: Malfunction indication 1
○ ○ ○ ○ ○
18: Reserved
19: Brake transistor output error
○ ○ ○ ○ ○
20: Warning output
○ ○ ○ ○ ○
21: Over-voltage warning
○ ○ ○ ○ ○
22: Over-current stall prevention warning
○ ○ ○
23: Over-voltage stall prevention warning
○ ○ ○ ○ ○
24: Operation mode indication (Pr.00-15=1)
○ ○ ○ ○ ○
25: Forward command
○ ○ ○ ○ ○
26: Reverse command
○ ○ ○ ○ ○
27: Output when current ≥ Pr.02-33
○ ○ ○ ○ ○
28: Output when current < Pr.02-33
○ ○ ○ ○ ○
29: Output when frequency ≥ Pr.02-34
○ ○ ○ ○ ○
30: Output when frequency < Pr.02-34
○ ○ ○ ○ ○
31: Power generation direction and status
verification
○ ○ ○ ○ ○
32: Power generation direction
○ ○ ○ ○ ○
33: Zero speed (actual output frequency)
○ ○ ○ ○ ○
34: Zero speed with Stop (actual output
frequency)
○ ○ ○ ○ ○
35: Fault output option 1 (Pr.06-22)
○ ○ ○ ○ ○
36: Fault output option 2 (Pr.06-23)
○ ○ ○ ○ ○
37: Fault output option 3 (Pr.06-24)
○ ○ ○ ○ ○
38: Fault output option 4 (Pr.06-25)
○ ○ ○ ○ ○
39: Reserved
40: Speed reached (including zero speed)
○ ○ ○ ○ ○
41: Reserved
42: STO Output Error
○ ○ ○ ○ ○
43–44: Direct Docking Mode only
45: Reserved
46:
Retrying after a fault has occurred indication
○ ○ ○ ○ ○
47: Direct Docking Mode only
48: Control output of
Circuit Contactor)
○ ○ ○ ○ ○
49: Emergency power mode action
○ ○ ○ ○ ○
50: Speed reached Pr.02-34
○ ○ ○ ○ ○
51: Brake torque test finished
○ ○ ○ ○ ○
52: AFE reset
○ ○ ○ ○ ○
