Delta VFD055ED43S User Manual

12 Descriptions of Parameter Settings | VFD-ED
12-02-10
18 Reserved
19
Brake transistor output error
Active when a brake transistor error is detected
20
Warning output Active when a warning is detected.
21
Over-voltage warning Active when an over-voltage is detected.
22
Over-current stall prevention
warning
Active when an over-current stall prevention is detected.
23
Over-voltage stall prevention
warning
Active when an over-voltage stall prevention is detected.
24
Operation mode indication
Active when the operation command is controlled by an external
terminal (Pr.00-15=1).
25
Forward command Active when the operation direction is forward.
26
Reverse command Active when the operation direction is reverse.
27
Output when current ≥ Pr.02-
33
Active when current is ≥ Pr.02-33.
28
Output when current < Pr.02-
33
Active when current is < Pr.02-33.
29
Output when frequency ≥
Pr.02-34
Active when frequency is ≥ Pr.02-34.
30
Output when frequency <
Pr.02-34
Active when frequency is < Pr.02-34.
31
Power generation direction
and status verification
Activate when the power generation direction is verified.
32
Power generation direction Activate when the power generation direction runs forward.
33
Zero speed (actual output
frequency)
Active when the actual output frequency is 0. The drive should be in
RUN mode.
34
Zero speed with stop (actual
output frequency)
Active when the actual output frequency is 0 or Stop. The drive should
be in RUN mode.
35
Fault output option 1 (Pr.06-
22)
Active when Pr.06-22 is ON.
36
Fault output option 2 (Pr.06-
23)
Active when Pr.06-23 is ON.
37
Fault output option 3 (Pr.06-
24)
Active when Pr.06-24 is ON.
38
Fault output option 4 (Pr.06-
25)
Active when Pr.06-25 is ON.
39 Reserved
40
Speed reached (including
zero speed)
Active when the output frequency reaches the frequency setting. Can
be used to work with Pr.02-43.
41 Reserved
