12 Descriptions of Parameter Settings | VFD-ED
42 STO Output Error
Status of drive
Status of safety output
Status A (MO=42)
Normal Broken circuit (open) *See Table 16-3 for
STO Short circuit (closed) settings of logic
STL1–STL3 Short circuit (closed) output B
43–44 Direct Docking Mode only Contact Delta for more information
45 Reserved
46
Retrying after a fault has
occurred indication
Retry multiple outputs after an error has occurred. When the retry
period has finished, MO stops.
47 Direct Docking Mode only Contact Delta for more information
48
Control output of MPSCC
(Motor Phase Short Circuit
Contactor)
Active when the drive receives a STOP command.
49
Emergency power mode
action
Active when the drive receives a signal from the host controller (Pr.02-
01–02-08=54) after Pr.06-71 time.
50 Speed reached Pr.02-34
Active when drive’s output frequency is > Pr.02-34, and PGF3 error
will be triggered.
51 Brake torque test finished Active when brake torque test is finished.
52 AFE reset Use with AFE series product
Multi-function Output Terminal Direction
Control Mode
VF VFPG SVC FOCPG FOCPM Default: 0
Settings 0–65535
This parameter uses bit setting. If the bit is 1, the multi-function output terminal acts in the opposite
direction. For example, if you set Pr.02-11 to 1 and the forward bit is 0, Relay 1 is ON when the drive is
running and OFF when the drive is stopped.
Bit 11 Bit 10 Bit 9 Bit 8 Bit 7 Bit 6 Bit 5 Bit 4
- - MO6 MO5 MO4 MO3 MO2 MO1 R2A R1A MRA RA
Serial Start Signal Selection
Control Mode
VF VFPG SVC FOCPG FOCPM Default: 0
Settings 0: According to FWD/REV signal
1: According to Enable drive function signal
Selects the contactor serial start method.
0: According to FWD/REV signal, the motor starts to run after the Enable signal MI = 40 is ON.
1: According to Enable signal, the contactor, mechanical brake and DC brake all follow parameters’ setting
to run after FWD/REV and Enable are ON.
