Chapter 1. Description of Hybrid Servo Drives I VFD-VJ
1-4
Air Cooled VFD-VJ-C 460V models
Frame Size C D E4
Model VFD-_ _ _VL43_-J 110 C 150 C 185 C 220 C 300 C 370 C 450 C 550 C 750 C
Power (KW) 11 15 18.5 22 30 37 45 55 75
Horse Power (HP) 15 20 25 30 40 50 60 75 100
Output
Rated Output
Current( (A)
21 27 34 41 60 73 91 110 150
Continuous Output
Current for 60 sec (A)
36 46 58 70 102 124 155 187 255
Continuous Output
Current for 20 sec (A)
42 54 68 82 120 146 182 220 300
Carrier Frequency
(Hz)
4k ~ 10k adjustable
Power
Supply
Rated Input
Current(A)
24 30 37 47 60 73 91 110 150
Rated Input
Voltage(V)
Three-Phase Power: 380V ~ 480V, 50Hz / 60Hz
Mains Voltage
Tolerance
-15% ~ +10% (323V ~ 528V)
Mains Frequency
Tolerance
±5% (47~63Hz)
Weight (kg) 9 13 36 46
Brake Units Built-In
*When the carrier frequency is 4~ 5kHz, the rated current reaches 100%. However, as the carrier frequency increases,
the rated current decreases. Therefore, the overload capacity decreases. Refer to parameter Pr01-33 for more
information.
**To continuously improve our products, we reserve the rights to change features and specifications without further
notice.
