Delta VFD110VL43C-J User Manual

Chapter 1. Description of Hybrid Servo Drives | VFD-VJ
1-3
1-2 Product Specifications
Air Cooled VFD-VJ-A 230V models
Frame Size
C D
Model VFD-_ _ _VL23A-J
110 150 185 220
Power (KW)
11 15 18.5 22
Horse Power (HP)
15 20 25 30
Rated Output Current(A)
41.1 53 70 79
Output
Continuous Output
Current for 60 sec (A)
62 90 119 79
Continuous Output
Current for 20 sec (A)
70 106 140 119
Power
supply
Rated Input Current(A)
47 56 73 90
Rated Input
Voltage(V)
Three-Phase Power: 200~240V 50/60Hz
Mains Voltage
Tolerance
±10% (180~264V)
Mains Frequency
Tolerance
±5% (47~63Hz)
Weight (kg) 10 13 13 13
Air Cooled VFD-VJ-C 230 models
Frame Size E4
Model VFD-_ _ _VL23_-J 300 C 370 C
Power (KW) 30 37
Horse Power (HP) 40 50
Output
Rated Output Current(A) 120 146
Continuous Output
Current for 60 sec (A)
204 248
Continuous Output
Current for 20 sec (A)
240 292
Carrier Frequency
(Hz)
4k ~ 10k adjustable
Power
Supply
Rated Input
Current(A)
120 146
Rated Input
Voltage(V)
Three-Phase Power: 200V~240V, 50Hz/ 60Hz
Mains Voltage
Tolerance
-15% ~ +10% (170V~264V)
Mains Frequency
Tolerance
±5% (47~63Hz)
Weight (kg) 44
Brake Units Built-In

Delta VFD110VL43C-J Specifications

General

Brand	Delta
Model	VFD110VL43C-J
Category	Servo Drives
Language	English
