Chapter 4 Description of Parameters | VFD-VJ
4-68
Content Register Function
(Pr.00-04 #8)
2209H Display PG feedback (Pr.00-04 #9)
220AH Reserved
220BH
Display the signal value of the analog input terminal PS
with 4~20mA/ 0~10V mapped to 0~100%
220CH
Display the signal value of the analog input terminal PI
with 0~10V mapped to 0~100%
220DH
Display the signal value of the analog input terminal AUI with
-10~10V mapped to -100~100%
220EH Display the temperature of the power module IGBT (XXX.X °C)
220FH Display the temperature of the power capacitor (XXX.X °C)
2210H Display the status of digital input (ON / OFF)
2211H Display the status of digital output (ON / OFF)
2212H Reserved
2213H The corresponding CPU pin status of digital input (d.)
2214H The corresponding CPU pin status of digital output (O.)
2215H Reserved
2216H Reserved
2217H Reserved
2218H Reserved
2219H
Display the signal value of the analog input terminal QI with 0~10V
mapped to 0~100%
221AH Display the actual pressure value (XXX.X Bar)
221BH Display the kWh value (XXX.X kWh)
221CH Display the motor temperature (XXX.X °C)
221DH Over load rate of hybrid servo drive (XXX.X %)
221EH Over load rate of motor with last digit A of HES (XXX.X %)
221FH Display current at braking (XXX A)
2220H Display temperature of the braking chopper (XXX.X °C)
To Next Page
