3. Machine Adjustment Procedure
3-7
Set the Parameter 01-08
The rated current of the induction motor
Setting value
of Parameter
01-08
0~655.35 Amps
Set the Parameter 01-09
The rated power of the induction motor
Setting value
of Parameter
01-09
0.00 – 655.35kW
Set the Parameter 01-10
The rated speed (rpm) of the induction motor
Setting value
of Parameter
01-10
0~65535
Set the Parameter 01-11
Number of poles of the induction motor
Setting value
of Parameter
01-11
2~20
Check if the motor can be separated from the pump
1. If it can be separated, set the Parameter 01-07 as 1 and carry out a dynamic
measurement
2. If it cannot be separated, open the safety valve, enter the no-load current of the induction
motor 01-12 and set the Parameter 01-07 as 2. Then carry out the static measurement
Motor Parameter Auto Tuning
Setting
value of
Parameter
01-07
0: No function
1: Rolling test for induction motor(IM) (Rs, Rr, Lm, Lx, no-load current)
2: Static test for induction motor(IM)
3: Reserved
4: Auto measure the angle between magnetic pole and PG origin
5: Rolling test for PM motor
During the automatic measurement process of the induction motor, the digital keypad will
show the message “tun”. After the measurement is finished, the motor automatically shuts
down, and the measurement values are stored into Parameters 01-13 to 01-16.If the digital
keypad shows “AUE”, please check if the wiring is correct and if the parameters are set
correctly.
The machine will shut off the power and then supply the power again
