Delta VFD150VL43C-J User Manual

Chapter 2 Wiring | VFD-VJ
2-14
short-circuit object before connecting to the DC reactor.
+1
Jumper
DC reactor

For those models without built-in brake resistor, please connect external brake
unit and brake resistor (both of them are optional) to increase brake torque.

DO NOT connect [B2] or [-] to [+2/B1] directly to prevent drive damage.

Delta VFD150VL43C-J Specifications

General

Brand	Delta
Model	VFD150VL43C-J
Category	Servo Drives
Language	English
