Chapter 1 IntroductionC2000 Series
1-16
Frame F
F1: VFD900C23A; VFD1320C43A; VFD1600C43A
H1
H2
S1
S1
W
W1
S2
See Detail A
See Detail B
Detail A (Mounting Hole)
Detail B (Mounting Hole)
D2
D
D1
H3
S3
Unit: mm [inch]
Frame
W H D W1 H1 H2 H3
D1* D2 S1 S2 S3
F1
420.0
[16.54]
- 300.0
[11.81]
380.0
[14.96]
800.0
[31.50]
770.0
[30.32]
717.0
[28.23]
124.0
[4.88]
18.0
[0.71]
13.0
[0.51]
25.0
[0.98]
18.0
[0.71]
D1*: Flange mounting
