DEMA 801GAP User Manual

I-951 Page 4 of 8
Rev. F-43693 2/14/2018
Dispenser with Chemical Cabinets
1. Open the door(s) of the chemical cabinet(s) using the supplied key.
2. Position the dispenser on the wall and mark the screw locations.
3. Install the supplied anchors in the wall. Use two anchors and two screws for each
chemical cabinet.
4. Mount the dispenser to the wall with the supplied screws.
Metering Tips & Chemical Supply Tubes
1. Each dispenser is supplied with at least one metering tip
kit. Chose the appropriate color metering tip based on the
supplied chemical induction chart.
2. Remove any selector knobs (if installed) by pulling on the
knobs.
3. Remove the dispenser head by depressing the tab on the top
of the cover.
4. Screw the metering tip into the chemical barb on the
dispenser head.
5. Cut to length the chemical supply tube to remove excess
tubing.
6. Install a supplied ceramic weight onto the tube.
7. Push the tubing onto the proportioner barb.
8. Replace the cover and any selector knobs
9. Place the ceramic weight, tubing, and foot valve into the
chemical.
Water Supply
1. Water supply must have a pressure between 20 psi (1.38 bar) and 125 psi (8.62 bar).
2. Attach a garden hose to the water inlet of the unit.
Table 1: “Action Gap”/Proportioner Induction Flow Rates w/Standard 1/4" Barb and Tubing
Metering
Tip
Color
(1 GPM Flow Rate Action Gap Proportioner)
Injection Rates For Viscosities Shown
(4 GPM Flow Rate Action Gap Proportioner)
Injection Rates For Viscosities Shown
1 cps 75 cps 200 cps 1 cps 75 cps 200 cps
Oz/Gal Ratio Oz/Gal Ratio Oz/Gal Ratio Oz/Gal Ratio Oz/Gal Ratio Oz/Gal Ratio
Tan
1.03 125-1 0.76 168-1 0.38 333-1 0.33 387-1 0.26 500-1 0.12 1090-1
Orange
1.24 103-1 0.98 130-1 0.53 241-1 0.42 307-1 0.32 430-1 0.17 735-1
Turquoise
1.43 89-1 1.07 119-1 0.61 211-1 0.51 251-1 0.34 382-1 0.19 676-1
Pink
2.47 52-1 1.58 81-1 0.92 139-1 0.78 165-1 0.56 230-1 0.3 422-1
Light Blue*
3.05 42-1 2.1 61-1 1.06 121-1 0.87 147-1 0.67 192-1 0.33 391-1
Brown
3.48 37-1 2.31 55-1 1.15 111-1 0.99 129-1 0.74 174-1 0.37 345-1
Red
4.38 29-1 2.83 45-1 1.23 104-1 1.37 93-1 0.91 141-1 0.44 289-1
White
5.33 24-1 3.1 42-1 1.37 93-1 1.52 84-1 1.04 123-1 0.48 264-1
Green
6.38 20-1 3.63 35-1 1.4 91-1 1.72 74-1 1.22 105-1 0.52 244-1
Blue
6.77 19-1 3.78 34-1 1.45 88-1 2.13 60-1 1.27 101-1 0.54 239-1
Yellow
9.90 13-1 5.1 25-1 1.48 86-1 3.05 42-1 1.71 75-1 0.56 229-1
Black
15.00 9-1 6.54 20-1 1.53 84-1 4.50 28-1 1.96 65-1 0.57 224-1
Purple
24.94 5-1 7.28 18-1 1.57 82-1 7.75 17-1 2.4 53-1 0.59 217-1
Gray
35.94 4-1 8.5 15-1 1.64 78-1 9.86 13-1 2.54 50-1 0.63 204-1
No Tip
42.2 2-1 9.35 14-1 1.87 69-1 19.63 7-1 3.16 40-1 0.67 190-1
