Page 25 AB20020
Note: ??= 15 for Yellow Rim
56 for Off White Rim
ITEM PART # DESCRIPTION QTY
1 00004 WASHER, FLAT, .313 8
2 00059 WASHER, FLAT .375 4
3 00085 .50 FLAT WASHER 7
4 00103 TONGUE 1
5 00109 U-BOLT .50 X 3.50 SQUARE 6
6 00118-?? 15” x 8” RIM 2
7 00130-76 CLEVIS HITCH 1
8 00162-10 PLATFORM 1
9 00164-10 STEP FOR HCM 1
10 00165-10 SAFETY HANDRAIL F/HCM 1
11 00185 5/32” X 1” COTTER PIN 1
12 00214 WASHER, FLAT, .25 5
13 00372 BOLT .313NC X 1.50 HEX HEAD GR5 4
14 00523 BOLT, .375NC X 1.25 HEX HEAD GR. 5 10
15 00846-10 AXLE TUBE 3.5” X 72” 1
16 00955 U-BOLT, RND, .250NC X 1.00 2
17 00967 BOLT, .50NC X 1.25 HEX HEAD GR5 32
18 01254 BOLT, .50 NC X 1.50 HEX HEAD GR5 2
19 01792-76 BOOM MOUNT BRACKET 2
20 01887 U-BOLT .375 x 2.50 SQUARE 8
21 02094-76 PLUMBING SUPPORT 1
22 02157 BOLT .375NC X 6.00 HEX FULL THREAD 8
23 02178 NUT, .50NC LOCK, NY. INSERT 46
24 02187-95 LOCK PIN 1
25 02208 LOCK SPRING 1
26 02592 NUT, .375NC NYLON LOCK 34
27 02693-76 BOOM BRACE 2
28 02700-10 WHEEL CARRIER UPRIGHT 2
29 02713-10 HCM MAIN FRAME 1
30 02714-10 PLATFORM MOUNTING BRACKET 2
31 02772 NUT, .25NC LOCK NYLON INSERT 4
32 02802 NUT, .313 NC NYLON LOCK 4
33 05558-76 SAFETY STAND HOLDER 1
34 05559-76 SQUARE SAFETY STAND 1
35 05784-95 LARGE STRAP ANCHOR 4
36 07805 JACK, 2000#, 10” SIDEWIND W/ PIN 1
37 07966-76 ASSY, JACK STORAGE MOUNT 1
38 09602-76 BOOM MOUNT TUBE (2.5” X 72”) 2
39 09828 4” STRAP 82” (BLACK) 2
Please order replacement parts by PART NO. and DESCRIPTION
ITEM PART # DESCRIPTION QTY
40 12793 YELLOW EYE WASH TANK WITH LID 1
41 14471-76 2.5 GAL. EYE WASH TANK BRACKET 1
42 5157-10 6-BOLT HUB ASSEMBLY 2
A 00110 OIL SEAL(16289) 1
B 01464 INNER CUP (JL69310) 1
C 00111 INNER CONE BEARING (JL 63949) 1
D 01465 OUTER CUP (LM 67010) 1
E 00113 OUTER CONE BEARING (LM 67048) 1
F 00114 WASHER 1
G 00115 CASTLE NUT 1
H 00116 5/16” X 1-1/2” COTTER PIN 1
I 00120 LUG BOLT .5” -20 UNF X 1 6
J 00117 DUST CAP 1
43 PE300RA 300 GAL POLY TANK W/ AGITATION 1
- 09319 8” DIAMETER LID 1
44 PL2S SPOUT F/ EYE WASH TANK 1
Please order replacement parts by PART NO. and DESCRIPTION
HCM (300 GALLON) MAIN PARTS LIST
To Next Page
