Demco RMLE - Foam Marker (DFM60) Mounting Bracket Parts Breakdown and List

AC20021 Page 13
RML
6.00”
2
2
2
1
3
3
3
REF. PART
NO. NO. QTY. DESCRIPTION
PARTS LIST
Please order replacement parts by PART NO. and DESCRIPTION.
ASSEMBLY
1
1. Begin by bolting on the Extension Bracket
(#1) using six 1/2” x 1-1/4” hex head bolts (#3)
and nylon insert locknuts (#4).
2. Continue assembly with step 1 of DFM60
Foam Marker owners manual.
1. 03746-10 2 Extension Bracket
2. 00967 6 1/2” x 1-1/4” Hex Head Bolts (Gr.5)
3. 02178 6 1/2” Nylon Insert Locknut
4. 00085 2 1/2” Flat Washer
4
INSTALLATION
OPTIONAL REAR MOUNT EXTENSION BRACKET FOR FOAM MARKER (DFM 60)
