Den-Sin C-250E - Page 15

3. Maintenance and Troubleshooting
C-250E R14 Page 15
 Valve Assembly:
1. Install the valve seat O-ring squarely into the bottom of the manifold. (See Fig.5)
2. Insert the valve assembly squarely into the port pushing it into the O-ring. (See Fig.6)
3. Install the valve cap and torque to the proper specification. (See Fig.7)
Fig.5
Fig.6
Fig.7
