DENAFRIPS HERMES DDC - 5 Specifications

© DENAFRIPS CO. LTD. & VINSHINE AUDIO PTE. LTD. (SINGAPORE)
ALL RIGHTS RESERVED
5. SPECIFICATIONS
Description Parameters
AC Power
Worldwide AC Power Supported 110 - 230V, 50/60Hz
In 110VAC mains, the min voltage ranges from 92V to max 126V
In 230VAC mains, the min voltage ranges from 184V to max 253V
Power Consumption < 30W
Digital Input
Coax SPDIF via RCA
TOSLink x 1
AES/EBU x 1
USB
External Clock Input
45.15
84
MHz
49.152Mhz
Digital Output
Coax SPDIF via RCA
TOSLink x 1
AES/EBU x 2
I²S HDMI LVDS Standard
I²S RJ45 LVCMOS Standard
Supported Format (DSD)
DSD64 All Input
DSD64 – DSD512 USB & I²S Only
Supported Format (PCM)
24bit/44.1, 48, 88.2, 96, 176.4, 192 kHz All Input
44.1 – 768 kHz on USB & 44.1 – 384kHz on I²S Only
Dimension
3
3
0W x 2
4
0D x
50
H mm (Feet +18mm)
Weight
6.0
kg
