Denkovi DAEnetIP2 v2 User Manual

DAEnetIP2 v2 User Manual
21 Apr 2020
- 10 -
5.2. DAEnetIP2 v2 ports description
Table 5.1. I/O Ports
Port JP3 (P3)
digital outputs
Port JP4 (P5)
digital outputs
Port JP5 (P6)
(digital/analog inputs)
Pin N
Bit
Func
Dir
Bit
Func
Dir
Bit
Func
Dir
1
1
Free
I/O
1
Free
I/O
1
Free
Ain
2
2
Free
I/O
2
Free
I/O
2
Free
Ain
3
3
Free
I/O
3
Free
I/O
3
Free
Ain
4
4
Free
I/O
4
Free
I/O
4
Free
Ain
5
5
Free
I/O
5
Free
I/O
5
Free
Ain
6
6
Free
I/O
6
Free
I/O
6
Free
Ain
7
7
Free
I/O
7
Free
I/O
7
Free
Ain
8
8
Free
I/O
8
Free
I/O
8
Free
Ain
9
-
GND
PWR
-
+3.3V
PWR
-
+3.3V(Vref)
PWR
10
-
GND
PWR
-
GND
PWR
-
GND
PWR
Legend:
o “Free” – the pin is free to be used by user.
o “XXXXXX” - the pin is reserved for special function – cannot be accessed.
o “In” – the pin is digital input
o “Out” – the pin is digital output
o "I/O" – the pin is digital input or output depending the settings
o “Ain” – analog input
