DAEnetIP2 v2 User Manual
21 Apr 2020
13. Appendix 4. Port forwarding - for advanced users
This appendix describes how to access the DAEnetIP2 v2 over the Internet. The demonstration
is done with router "TP-Link TL-WR340G", but it may be done with any other router supporting
"Port Forwarding" function. Bellow are given the steps you have to go through to make "Port
Forwarding".
1. Adjust DAEnetIP2 v2 network ports. These ports are:
o SNMP port, by default 161
o HTTP port, by default 80
DAEnetIP2 v2 will accept any valid integer number for port >1025 and <65535. Port numbers
from 0 to 1024 will be accepted as 161. The same is with port 80.
Let's say we would like to adjust for example:
o Port 10080 for HTTP
o Port 10161 for SNMP
This may easily be done from the DAEnetIP2 v2 web server -> Setup page
2. These ports must be set in the forwarding rules inside the router as it is shown on the figure
bellow
Figure 13.1. Port forwarding
The IP address 192.168.1.11 is actually the internal address of the DAEnetIP2 v2.
3. Now it is possible to access the DAEnetIP2 v2 from everywhere outside the LAN
(including over the Internet).
xxx.xxx.xxx.xxx:10080 - is the web server of the module
snmpget -v1 -c 000000000000 xxx.xxx.xxx.xxx:10161 .1.3.6.1.4.1.42505.9.1.1.0 - snmp
command for accessing the module (get the IP)
xxx.xxx.xxx.xxx - the public IP of the router or it's DNS name.
Good online guide for port-forwarding is the bellow link:
http://portforward.com/english/routers/port_forwarding/
