Denkovi DAEnetIP2 v2 User Manual

DAEnetIP2 v2 User Manual
21 Apr 2020
- 29 -
listen port for Web
server. Allowed values
80 and >1024
INTEGER(0..65535)
x.9.1.23.0
cfgSNMPport
read-write
(fw>=4.094) Defines
listen port for SNMP
server. Allowed values
161 and >1024
INTEGER(0..65535)
x.9.1.25.0
cfgP3Dir
read-write
Bit mask with direction
of P3 pins. 1-Output, 0-
Input
INTEGER(0..255)
x.9.1.26.0
cfgP5Dir
read-write
Bit mask with direction
of P5 pins. 1-Output, 0-
Input
INTEGER(0..255)
x.9.1.27.0
cfgPortPullUps
read-write
Disable/Enable pull-ups
for P3 and P5 I/O pins.
0-Disable, 1-Enable
INTEGER(0..1)
x.9.1.29.0
cfgP5DupRST
read-write
Bit mask showing on
which P5 pins to
duplicate TargetRST
signal. Pins must be
outputs in cfgP5Dir.
Available from v.4.097
INTEGER(0..255)
x.9.1.30.0
cfgDefault
read-only
Reading this OID will
load factory default
settings of DAEnetIP2
v2and restart
DAEnetIP2 v2.
INTEGER
x.9.1.31.0
cfgDigitalInput
sFilter
read-write
Digital Inputs Filter
(0..200), ms.
Value 0 disables the
filter.
INTEGER (0..200)
x.9.1.32.0
cfgAnalogInput
sFilter
read-write
Analog Inputs Filter
(0..30), sec.
Value 0 disables the
filter.
INTEGER (0..30)
9.2. Analog traps
Table 9.2. Analog traps
OID
Name
Access
Description
Syntax
x.9.1.122.1.0
atrPin1Low
read-write
Pin low threshold
INTEGER(0..1023)
x.9.1.122.2.0
atrPin1High
read-write
Pin high threshold
INTEGER(0..1023)
x.9.1.122.3.0
atrPin2Low
read-write
Pin low threshold
INTEGER(0..1023)
x.9.1.122.4.0
atrPin2High
read-write
Pin high threshold
INTEGER(0..1023)
x.9.1.122.5.0
atrPin3Low
read-write
Pin low threshold
INTEGER(0..1023)
x.9.1.122.6.0
atrPin3High
read-write
Pin high threshold
INTEGER(0..1023)
x.9.1.122.7.0
atrPin4Low
read-write
Pin low threshold
INTEGER(0..1023)
x.9.1.122.8.0
atrPin4High
read-write
Pin high threshold
INTEGER(0..1023)
x.9.1.122.9.0
atrPin5Low
read-write
Pin low threshold
INTEGER(0..1023)
