DAEnetIP2 v2 User Manual
21 Apr 2020
- 32 -
byte
9.5. Control port P5 (Digital outputs)
Table 9.5. Control port P5
OID
Name
Access
Description
Syntax
x.9.2.2.1.0
pctrlP5pin1
read-write
Port5 pin1 data
INTEGER { High(1), Low(0) }
x.9.2.2.2.0
pctrlP5pin2
read-write
Port5 pin2 data
INTEGER { High(1), Low(0) }
x.9.2.2.3.0
pctrlP5pin3
read-write
Port5 pin3 data
INTEGER { High(1), Low(0) }
x.9.2.2.4.0
pctrlP5pin4
read-write
Port5 pin4 data
INTEGER { High(1), Low(0) }
x.9.2.2.5.0
pctrlP5pin5
read-write
Port5 pin5 data
INTEGER { High(1), Low(0) }
x.9.2.2.6.0
pctrlP5pin6
read-write
Port5 pin6 data
INTEGER { High(1), Low(0) }
x.9.2.2.7.0
pctrlP5pin7
read-write
Port5 pin7 data
INTEGER { High(1), Low(0) }
x.9.2.2.8.0
pctrlP5pin8
read-write
Port5 pin8 data
INTEGER { High(1), Low(0) }
x.9.2.2.33.0
pctrlP5byte
read-write
I/O port data as
single byte
INTEGER(0..255)
9.6. Returned values are from 10bit Analog to Digital Converter
Table 9.6. Returned values from ADC
OID
Name
Access
Description
Syntax
x.9.2.3.1.0
pctrlP6pin1
read-only
ADC Channel 1
INTEGER(0..1023)
x.9.2.3.2.0
pctrlP6pin2
read-only
ADC Channel 2
INTEGER(0..1023)
x.9.2.3.3.0
pctrlP6pin3
read-only
ADC Channel 3
INTEGER(0..1023)
x.9.2.3.4.0
pctrlP6pin4
read-only
ADC Channel 4
INTEGER(0..1023)
x.9.2.3.5.0
pctrlP6pin5
read-only
ADC Channel 5
INTEGER(0..1023)
x.9.2.3.6.0
pctrlP6pin6
read-only
ADC Channel 6
INTEGER(0..1023)
x.9.2.3.7.0
pctrlP6pin7
read-only
ADC Channel 7
INTEGER(0..1023)
x.9.2.3.8.0
pctrlP6pin8
read-only
ADC Channel 8
INTEGER(0..1023)
