Filling Points
The hydraulic filler is located in the
engine compartment at the rear of the
vehicle. The hydraulic oil level can be
checked using the dipstick,the level
should be maintained between the High
and Low markings.
The coolant filler cap is located behind
an access door flap at the rear right
corner of the vehicle. The coolant level
sight gauge is mounted below it to the
rear.
WARNING
Do not remove the cap while
the system is hot/under
pressure. Suddenly removing
the cap will allow scalding
steam or coolant spray to
escape, possibly resulting in
injury.
Hydraulic Oil Coolant
