63
Emergency Repairs
The jack may be positioned in the
following locations:
Directly under the base of the air
spring.
Under the chassis frame, where the
crossmember in front of the rear
axle crosses the frame longitudinal.
Front
CAUTION
The jack must be directly
beneath the air spring base.
Never place the jack under the
unsupported span of the
member that connects the two
air spring bases.
Rear Axle Jacking Points
