Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
q
W0 W1 W2
w e r t y
ui
oQ0Q1Q2Q3Q4Q5Q6Q7Q8Q9u
q RS-232C connector ····································· (24)
w Analog audio connectors (AUDIO) ··········· (13)
e PRE OUT connectors ···························· (19, 23)
r EXT. IN connectors ····································· (18)
t AC inlet (AC IN) ··········································· (24)
y AC OUTLETS ··············································· (24)
u Speaker terminals (SPEAKERS) ················ (10)
i HD Radio antenna terminals
(DTU ANTENNA) ········································
(21)
o COMPONENT VIDEO connectors ·············· (13)
Q0 Digital audio connectors
(OPTICAL / COAXIAL / BNC) ··············· (13, 23)
Q1 HDMI connectors ········································ (12)
Q2 ETHERNET connector ································ (22)
Q3 USB port ······················································ (19)
Q4 XM connector (SAT TU) ····························· (20)
Q5 WLAN ANTENNA terminal ························ (22)
Q6 FM/AM antenna terminals
(TUNER ANTENNA) ···································· (21)
Q7 DENON LINK connector ····························· (18)
Rear Panel
Q8 TRIGGER OUT jacks ··································· (24)
Q9 REMOTE CONTROL jacks ·························· (23)
W0 DOCK CONTROL jack ································· (14)
W1 SIGNAL GND terminal ······························· (14)
W2 VIDEO / S-VIDEO connectors ···················· (13)
Getting Started
AVR5308CIEU_100_初校作成中.indd 6 2008/05/26 10:17:10
