Denon AVR-1604 Service Manual

11
11
AVR-1604/684 / AVC-1580
Pin
No.
Pin Name FunctionI/O
77 PWR DOWN I POWER DOWN DETECT
78 RDS CLK O TDA7330 CONTROL CLOCK
79 RDS DATA O TDA7330 CONTROL DATA
80 NC 
81 VIDEO MUTE O VIDEO MUTE
82 M32 INTREQ I/O MELODY32 CONTROL
83 VIDEO SEL1 O VIDEO SELECT1
84 VIDEO SEL2 O VIDEO SELECT2
85 REMOCON I REMOTE CONTROL SIGNAL INPUT
86 GND 
87 GND 
88 VSS 
89 VDD 
90 NC 
91 NC 
92 PLL DATA O PLL CONTROL
93 PLL CLK O PLL CONTROL
94 PLL DT IN O PLL CONTROL
95 TU MUTE O TUNER MUTE
96 STEREO I STEREO DETECT
97 TUNED I TUNED DETECT
98 PLL CE O PLL CONTROL
99 NC 
100 NC 

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
