Denon AVR-1604 Service Manual

36
36
AVR-1604/684 / AVC-1580
C202 963 9004 711 Ceramic chip 0.1uF/50V
C203 963 9004 698 Ceramic chip 0.01uF/50V
C204 963 9006 476 Electrolytic 4.7uF/50V
C205 963 9004 711 Ceramic chip 0.1uF/50V
C207 963 9004 546 Ceramic 0.01uF/16V E2,EK,E2A
C208 963 9005 354 Ceramic chip 270pF/50V E2,EK,E2A
C209 963 9006 308 Electrolytic 10uF/50V E2,EK,E2A
C211,212 963 9004 614 Ceramic chip 27pF/50V E2,EK,E2A
C221 963 9006 324 Electrolytic 100uF/10V
C251 963 9006 366 Electrolytic 0.1uF/50V
C261,262 963 9004 575 Ceramic chip 100pF/50V
C267 963 9004 575 Ceramic chip 100pF/50V
C271 963 9006 337 Electrolytic 100uF/16V
C272 963 9006 308 Electrolytic 10uF/50V
C291,292 963 9004 517 Ceramic 0.022uF/50V
C293 963 9004 517 Ceramic 0.022uF/50V E3,EU,E2,EK,E2A
C301 963 9006 308 Electrolytic 10uF/50V
C302 963 9004 753 Ceramic chip 0.047uF/50V
C303 963 9006 434 Electrolytic 47uF/16V
C304 960 9003 108 Ceramic 0.022uF/25V
C305 963 9005 859 Electrolytic 47uF/16V
C306 963 9004 766 Mylar film 0.1uF/100V
C307 963 9006 379 Electrolytic 1uF/50V
C308,309 963 0021 900 Mylar film 0.047uF/100V
C310 963 9006 379 Electrolytic 1uF/50V
C311 963 9005 406 Ceramic chip 30pF/50V
C312 963 9005 859 Electrolytic 47uF/16V
C313 963 9005 419 Mylar film 0.047uF/63V
C321 963 9004 685 Ceramic chip 1000pF/50V
C322 963 9004 575 Ceramic chip 100pF/50V
C324,325 963 9004 575 Ceramic chip 100pF/50V
C331,332 963 9004 546 Ceramic 0.01uF/16V
C335,336 963 9004 546 Ceramic 0.01uF/16V
C381 963 9006 434 Electrolytic 47uF/16V
C382,383 963 9004 575 Ceramic chip 100pF/50V
C384,385 963 9006 379 Electrolytic 1uF/50V
C386 963 9004 753 Ceramic chip 0.047uF/50V
C387,388 963 9004 711 Ceramic chip 0.1uF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C391 963 9004 591 Ceramic chip 22pF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C392 963 9004 711 Ceramic chip 0.1uF/50V E3,EU,E2,EK,E2A,E1C,EUT,E1K
C393 963 9005 859 Electrolytic 47uF/16V E3,EU,E2,EK,E2A,E1C,EUT,E1K
OTHER PARTS GROUP
BD201,202 963 0053 800 BEADS INDUCTOR
CN201 963 0096 906 6P SHIELD WIRE
CN202 963 0099 408 4P WIRE E3,EU,E2,EK,E2A,E1C,EUT,E1K
CN302 963 0096 702 6P WIRE
CN931 963 0089 502 2P WIRE E2,EK,E2A,E1C,EUT,E1K
CP201 963 0097 604 6P connector base
CP202 963 0050 104 4P connector base E3,EU,E2,EK,E2A,E1C,EUT,E1K
CP301A 963 0111 205 20P FFC connector base
CP301B 963 0111 302 20P FFC connector base
CP303 963 0049 102 3P connector base
CP401 963 0088 008 10P connector base (TUC-P) E3,EU,E2,EK,E2A,E1C,EUT,E1K
CP402 963 0097 507 15P connector base (TUC-P)
CP552 963 0097 507 15P connector base (TUC-P)
Ref. No. Part No. Part Name Remarks New

Denon AVR-1604 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Audio output channels	6.1 channels
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Ethernet LAN	No
Supported radio bands	AM, FM
Product color	Black
Audio decoders	DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
