AVR-1604/684 / AVC-1580
C762FL,FR,SW 963 9004 575 Ceramic chip 100pF/50V
C763FL,FR,SB,SW 963 9004 753 Ceramic chip 0.047uF/50V
C764FL,FR 963 9004 627 Ceramic chip 33pF/50V
C764SW 963 9004 643 Ceramic chip 47pF/50V
C765FL,FR,SW 963 9006 308 Electrolytic 10uF/50V
C771,772 963 9006 447 Electrolytic 47uF/25V
C773 963 9006 379 Electrolytic 1uF/50V
C781C,FL,FR,SB,SL,SR,SW 963 9004 753 Ceramic chip 0.047uF/50V
C782C,SB,SW 963 9006 476 Electrolytic 4.7uF/50V
C782FL,FR,SL,SR 963 9006 308 Electrolytic 10uF/50V
C783C,SB,SL,SR 963 9004 630 Ceramic chip 39pF/50V
C783FL,FR 963 9004 669 Ceramic chip 56pF/50V
C783SW 963 9004 575 Ceramic chip 100pF/50V
C786SW 963 9006 476 Electrolytic 4.7uF/50V
C791,792 963 9006 447 Electrolytic 47uF/25V
OTHER PARTS GROUP
CN701 963 0086 204 19P connector socket (TUC-P)
CN702 963 0085 302 17P connector socket (TUC-P)
CN703 963 0085 409 10P connector socket (TUC-P)
CP551 963 0114 901 14P SHIELD WIRE
- 963 0094 005 INPUT CUSHION
- 963 0094 102 PLATE INPUT
- 960 0188 200 4P pin jack
- 960 0188 307 6P pin jack 2
Ref. No. Part No. Part Name Remarks New
